Victron Phoenix Smart IP43 Battery Charger 12V/50A/120-240V 1 Output + 1
SKU: PSC125051095
This is super light, compact, versatile and inexpensive. It has Bluetooth built-in so it can be programmed from your phone or tablet using Victron Connect. Its VE Direct port means you can connect it to a Cerbo GX. Its remote port means you can control it from a BMS. Its relay port means you can control external devices from it (only while connected to AC power). It has a 6 stage charge algorithm with storage mode for conventional batteries and a 3 stage algorithm for Lithium batteries. Its IP rating gives it limited protection from sprayed water.
- Manufacturer Victron Energy
- Commodity Code 85044083
- Dimensions (mm) (H x W x D) 180 x 249 x 100
- 85-265 volt input, 45-65 Hz, 12 volt 50 amp one main output plus an auxiliary low power output
- Aux output is 4 amps max.
- Power Factor >0.99
- Maximum input power setting 3 -10 amps
- Fully programmable charge algorithm accessed via a phone, tablet, Mac or PC using Bluetooth and /or VE Direct using the Victron Connect App
- 6 Stage charge algorithm for conventional batteries, 3 stage for lithium batteries
- IEC 320 C14 inlet with retainer clip
- Charge current 50 amps with low current mode of 25 amps available if needed
- Programmable relay
- VE Direct port
- Remote on-off
- Suitable for use with Li Ion batteries
- Can be used as a power supply with a fixed output voltage
- IP43 protection
